VFG-G30 & G32 HEPA Dust Extractors
The VFG-G30 and VFG-G32 HEPA Dust Extractors are high-capacity industrial vacuum systems engineered for concrete grinding, polishing, surface preparation, coating removal, and large-scale dust collection applications. Designed for demanding commercial and industrial environments, these units combine powerful airflow, H13 HEPA filtration, jet pulse filter cleaning, and continuous bagging technology to maximize dust control and productivity.
Built for professional contractors, the G30 and G32 are ideal companions for planetary grinders, scarifiers, shot blasters, and large surface preparation equipment. Their multi-stage filtration systems help capture fine airborne dust while maintaining consistent suction during extended operation.
Key Features
Contractor-Grade Dust Extraction
Designed for continuous operation in demanding jobsite conditions.
- High airflow performance
- Powerful suction capability
- Heavy-duty construction
- Industrial-grade filtration
- Daily contractor use
H13 HEPA Filtration System
Advanced two-stage filtration captures fine airborne dust particles.
- HEPA efficiency greater than 99.99% at 0.3 microns
- OSHA-oriented silica dust control
- Multi-stage filtration system
- Extended filter service life
- Improved jobsite air quality
Jet Pulse Filter Cleaning
The reverse-air jet pulse cleaning system allows operators to clean filters without opening the vacuum.
Benefits include:
- Maintains airflow performance
- Reduces downtime
- Extends filter life
- Prevents secondary dust exposure
- Improves productivity
Continuous Bagging Dust Collection
Designed for cleaner dust disposal and easier maintenance.
- Continuous folding bag system
- Reduced operator exposure
- Cleaner disposal process
- Increased jobsite efficiency
- Compatible with standard collection bags
Technical Specifications
| Specification | VFG-G30 | VFG-G32 |
|---|---|---|
| Voltage | 120V / 60Hz | 230V / 60Hz |
| Motor Configuration | 3 Motors | 3 Motors |
| Maximum Power | 2.4 kW / 3.2 HP | 3.6 kW / 4.8 HP |
| Current Draw | 16A | 12A |
| Maximum Airflow | 485 m³/h | 600 m³/h |
| Maximum Airflow | 285 CFM | 354 CFM |
| Airflow @ 2" Intake | 224 CFM | 270 CFM |
| Airflow @ 3" Intake | 247 CFM | 330 CFM |
| Maximum Vacuum | 200 mbar | 220 mbar |
| Water Lift | 81" H₂O | 90" H₂O |
| Hose Size | 24' × 2" | 24' × 2" |
| Inlet Diameter | 2.5" (63 mm) | 2.5" (63 mm) |
| Main Filter Efficiency | >99.5% @ 1 Micron | >99.5% @ 1 Micron |
| Main Filter Area | 49 ft² (4.5 m²) | 49 ft² (4.5 m²) |
| HEPA Filter Efficiency | >99.99% @ 0.3 Micron | >99.99% @ 0.3 Micron |
| HEPA Filter Area | 39 ft² (3 m²) | 39 ft² (3 m²) |
| Noise Level | 70 dB(A) | 70 dB(A) |
| Dimensions (L × W × H) | 30.7" × 23.2" × 57.5" | 30.7" × 23.2" × 57.5" |
| Weight | 149 lbs | 149 lbs |
Performance Comparison
VFG-G30
The G30 is designed for standard 120V power and provides strong dust extraction performance for medium to large grinding applications.
Best for:
- Concrete grinding
- Surface preparation
- Commercial flooring projects
- General contractor applications
- Jobsites with standard 120V power
VFG-G32
The G32 offers increased airflow and vacuum performance for larger equipment and production-focused environments.
Benefits include:
- 24% greater airflow than G30
- Higher vacuum pressure
- Better performance with large grinders
- Increased dust collection efficiency
- Enhanced production capabilities
Standard Accessories
Included with the dust extractor:
- 24 ft × 2" Vacuum Hose
- Aluminum S-Wand
- Floor Brush Tool
- Continuous Bagging System
- HEPA Filtration System
Additional accessories may vary by package configuration.
Applications
Concrete Grinding
- Planetary grinders
- Edge grinders
- Surface preparation equipment
- Concrete profiling
Concrete Polishing
- Metal bond grinding
- Resin polishing
- Polished concrete projects
Surface Preparation
- Epoxy removal
- Coating removal
- Thinset removal
- Adhesive removal
Industrial Dust Collection
- Manufacturing facilities
- Warehouses
- Commercial construction
- Industrial maintenance
Benefits
Maximum Dust Collection Performance
The high airflow design efficiently captures concrete dust at the source for cleaner operation and improved productivity.
Reduced Maintenance
Jet pulse cleaning minimizes filter maintenance while maintaining suction performance throughout the workday.
OSHA-Oriented Dust Control
Advanced H13 HEPA filtration helps contractors control airborne dust generated during grinding and surface preparation.
Original: $3,650.00
-65%$3,650.00
$1,277.50
