HRC 650 SX/RX/AD Remote Controlled Floor Grinder with DCT System DCT
The DCT system allows you to choose to smooth use only using the rotation of the tools (DCT ON mode), or with the classic complete rotation of the planetary (DCT OFF mode).
MAIN CHARACTERISTICS:
Single-shell chassis, robust and compact for less space.
Tempered stainless steel planetary and gear box. Fully geared transmission.
180 ° overturning system for extra weight. The displaced weights increase the grinding pressure. The weights moved back facilitate the tilting operation for tool changes (Optional).
Third wheel for easy transportation and for operations on very large surfaces (Optional).
All functions available on remote controls.
On board batteries for machine self-displacement (RX/AD version).
Utensils free quick attachment system for diamond tools (RX/AD version).
46-liter water tanks.
Powerful front and rear LED spotlights (Optional).
Noise reduction levitating planetarium.
2 Year Warranty: The GUARANTEE for machines equipped with "hour counter" is up to 2 years or 600 hours of work.
Model
HRC 650 SX
HRC 650 RX
HRC 650 AD
Motor
10 HP
15Hp
15Hp
Drive Inverter
11 kW
11kW
11kW
Volt
380-480
380-400
380-400
Hertz
50/60
50/60
50/60
Amp
25
25
25
Tools Speed
300-1300 rpm
300-1300 650
300-1300 650
Work Diameter
650mm
Tools Size
3x240mm
3x240mm
3x240mm
Water Tank
46 lt
46lt
46lt
Size LxAxP cm
120x125x67
120x125x67
120x125x67
Weight
280 Kg
534 Kg
534kg
ESTIMATED PRODUCTION
Concrete Polishing 7 step
12-17 m2/h
Concrete Grinding 1 step
50-90 m2/h
Terrazzo Polishing 5 step
11-17 m2/h
Resin Removal 1 step
45-85 m2/h
Paint Removal 1 step
45-85 m2/h
Marble Polishing 5 step
8-13 m2/h
Granite Polishing 7 step
5-8 m2/h
Model
HRC 650 SX/RX/AD
Volume
1.31 m3
Size
120x80x136 cm
Weight
320 Kg
Select Models
From $14,254.96
Original: $40,728.47
-65%
HRC 650 Remote Controlled Floor Grinder—
$40,728.47
$14,254.96
Description
HRC 650 SX/RX/AD Remote Controlled Floor Grinder with DCT System DCT
The DCT system allows you to choose to smooth use only using the rotation of the tools (DCT ON mode), or with the classic complete rotation of the planetary (DCT OFF mode).
MAIN CHARACTERISTICS:
Single-shell chassis, robust and compact for less space.
Tempered stainless steel planetary and gear box. Fully geared transmission.
180 ° overturning system for extra weight. The displaced weights increase the grinding pressure. The weights moved back facilitate the tilting operation for tool changes (Optional).
Third wheel for easy transportation and for operations on very large surfaces (Optional).
All functions available on remote controls.
On board batteries for machine self-displacement (RX/AD version).
Utensils free quick attachment system for diamond tools (RX/AD version).
46-liter water tanks.
Powerful front and rear LED spotlights (Optional).
Noise reduction levitating planetarium.
2 Year Warranty: The GUARANTEE for machines equipped with "hour counter" is up to 2 years or 600 hours of work.
Model
HRC 650 SX
HRC 650 RX
HRC 650 AD
Motor
10 HP
15Hp
15Hp
Drive Inverter
11 kW
11kW
11kW
Volt
380-480
380-400
380-400
Hertz
50/60
50/60
50/60
Amp
25
25
25
Tools Speed
300-1300 rpm
300-1300 650
300-1300 650
Work Diameter
650mm
Tools Size
3x240mm
3x240mm
3x240mm
Water Tank
46 lt
46lt
46lt
Size LxAxP cm
120x125x67
120x125x67
120x125x67
Weight
280 Kg
534 Kg
534kg
ESTIMATED PRODUCTION
Concrete Polishing 7 step
12-17 m2/h
Concrete Grinding 1 step
50-90 m2/h
Terrazzo Polishing 5 step
11-17 m2/h
Resin Removal 1 step
45-85 m2/h
Paint Removal 1 step
45-85 m2/h
Marble Polishing 5 step
8-13 m2/h
Granite Polishing 7 step
5-8 m2/h
Model
HRC 650 SX/RX/AD
Volume
1.31 m3
Size
120x80x136 cm
Weight
320 Kg
