GrindLazer HP DC1520 E DCS(Depth Control System) Self-Propelled Electric Scarifier, Low-Speed Pulley Kit

Graco GrindLazer HP DC1520 E DCS Self-Propelled Electric Scarifier, High-Speed Pulley Kit

The Graco GrindLazer HP DC1520 E DCS Self-Propelled Electric Scarifier, High-Speed Pulley Kit is a heavy-duty, high-production walk-behind scarifier designed for precision surface preparation in commercial and industrial environments. Built for demanding concrete and asphalt removal applications, this machine features a 20 HP electric motor (480V, 3-phase), Graco’s advanced electronic Depth Control System (DCS), and a 16-inch cutting width to deliver consistent performance, reduced operator fatigue, and highly accurate material removal. The High-Speed Pulley Kit is optimized for diamond and PCD tooling, making it especially effective for coating removal, profiling, and surface preparation work requiring controlled aggression and precision.

Product Information

The DC1520 E DCS is engineered for environments where electric power is preferred or required, such as indoor facilities or low-emission job sites. Its self-propelled hydrostatic drive system allows operators to precisely control forward speed, improving consistency across large surface areas while minimizing physical strain.

The integrated DCS (Depth Control System) removes the need for manual depth adjustments or guesswork. Operators can set a zero reference point and then adjust cutting depth in precise 0.01-inch increments using the control interface, with real-time feedback displayed for accuracy and repeatability. This ensures uniform surface profiling across long runs and large slabs.

Powered by a 20 HP, 480V electric motor, the DC1520 E DCS provides quiet, low-emission operation compared to gas or propane models, making it suitable for enclosed or regulated environments. Its heavy-duty steel chassis, low-vibration design, sealed long-life bearings, and quick-change side plate contribute to durability, ease of maintenance, and long service life. A built-in vacuum port allows connection to dust collection systems such as the Graco LazerVac™ for improved jobsite cleanliness.

Common Applications and Uses

The GrindLazer HP DC1520 E DCS is commonly used for:

• Concrete surface preparation

• Concrete scarifying and profiling

• Coating removal (epoxy, paint, polyurea, polyurethane)

• Industrial flooring preparation

• Warehouse floor leveling and restoration

• Parking garage surface preparation

• Bridge deck rehabilitation

• Airport runway and taxiway maintenance

• Highway and roadway surface profiling

• Expansion joint and repair preparation

• Overlay and membrane removal

• Decorative concrete surface texturing

• Slab correction and leveling

• Commercial interior slab preparation

• Large-scale infrastructure maintenance

Technical Specifications

Specification	Details
Manufacturer	Graco
Product Name	GrindLazer HP DC1520 E DCS Self-Propelled Electric Scarifier, High-Speed Pulley Kit
Manufacturer Part No.	25P476
Power Source	Electric
Motor	20 HP, 480V, 3-phase
Starting System	Electric
Drive System	Variable-speed hydrostatic self-propelled
Cutter Type	Drum
Cutter Drum Diameter	10 in (254 mm)
Maximum Cutting Width	16 in (406 mm)
Production Rate	Up to ~3,500 sq ft/hour*
Depth Control	Electronic DCS (0.01 in increments)
Vacuum Port	Yes
Frame	Heavy-duty all-steel chassis
Pulley Kit	High-speed (diamond & PCD optimized)

Features

• High-production self-propelled electric scarifier for precision surface preparation

• 20 HP, 480V electric motor for low-emission operation

• Electronic Depth Control System (DCS) for precise depth adjustment

• Real-time depth display with programmable zero point

• Depth adjustments in 0.01-inch increments

• Variable-speed hydrostatic drive for controlled operation

• High-speed pulley kit optimized for diamond and PCD tooling

• 16-inch maximum cutting width for efficient material removal

• Quick-change side plate for simplified drum maintenance

• Heavy-duty steel chassis for durability in demanding environments

• Low-vibration design for improved operator comfort

• Long-life sealed bearings for extended service intervals

• Integrated dust port compatible with LazerVac™ systems

• Ideal for indoor and low-emission jobsite requirements

Compatible Applications

This machine is suitable for concrete and asphalt surfaces in warehouses, manufacturing facilities, distribution centers, parking structures, airports, municipal buildings, commercial interiors, and infrastructure projects requiring electric-powered, low-emission surface preparation with precise depth control.

Standard Equipment

The GrindLazer HP DC1520 E DCS typically includes the scarifier unit, 20 HP electric motor (480V, 3-phase), High-Speed Pulley Kit, electronic DCS controller system, hydrostatic drive system, heavy-duty steel frame, quick-change side plate, integrated vacuum port, and operator documentation.
