All Shield EX

All Shield EX is an oil and stain resistant penetrating concrete and stone protectant for interior and exterior surfaces

All Shield WB is a low-VOC, waterborne, synthetic-modified silane-siloxane concrete protectant designed to provide long-lasting protection against water intrusion, oil contamination, food stains, moisture damage, and deicing salts. This penetrating sealer bonds directly with concrete and stone surfaces while maintaining breathability, helping preserve the appearance and durability of the substrate.

Unlike film-forming coatings, All Shield WB penetrates below the surface to create invisible protection without changing the natural appearance of concrete, brick, pavers, or stone. The result is a colorless, non-yellowing, skid-resistant finish suitable for both interior and exterior applications.

---

Key Features & Benefits

Superior Oil & Stain Resistance

Provides excellent protection against:

• Motor oil
• Food stains
• Grease
• Water intrusion
• Common liquid contaminants

This makes All Shield WB ideal for commercial, industrial, and high-traffic environments.

Water-Based Low VOC Formula

The environmentally conscious formula complies with:

• SCAQMD regulations
• OTC regulations
• LADCO requirements

Making it suitable for projects requiring low-VOC products.

Freeze-Thaw Protection

Reduces water penetration into concrete, helping minimize:

• Freeze-thaw damage
• Surface scaling
• Spalling
• Weather-related deterioration

Especially beneficial for parking structures, bridges, sidewalks, and exposed concrete surfaces.

Breathable Penetrating Formula

Allows trapped moisture vapor to escape while preventing liquid penetration from above. This helps maintain concrete integrity while reducing moisture-related damage.

Non-Yellowing Finish

Leaves behind a clear, invisible protective barrier without discoloring decorative concrete, stone, pavers, or masonry surfaces.

USDA Accepted

Approved for indirect food contact areas, making it suitable for food-processing and commercial facilities.

---

Common Applications

Commercial & Industrial Floors

Protects concrete floors exposed to:

• Oils
• Grease
• Vehicle traffic
• Chemical contamination

Automotive Service Facilities

Ideal for garages, maintenance facilities, repair shops, and service bays where oil and fluid exposure is common.

Driveways & Pavements

Helps prevent water penetration, staining, and weathering damage while preserving appearance.

Parking Structures

Protects parking decks and garages from deicing salts, moisture intrusion, and long-term deterioration.

Bridges & Marine Structures

Provides additional protection against harsh environmental conditions, salt exposure, and moisture attack.

Natural & Manufactured Stone

Suitable for natural stone, synthetic stone, brick, concrete pavers, and decorative concrete applications.

---

Recommended Surfaces

All Shield WB can be used on:

• Concrete floors
• Decorative concrete
• Concrete pavers
• Brick
• Natural stone
• Manufactured stone
• Driveways
• Sidewalks
• Parking structures
• Bridges
• Marine platforms

---

Application Instructions

Surface Preparation

For best results:

• Surface must be clean and dry.
• Remove dirt, oil, grease, curing residue, and contaminants.
• Existing sealers must be removed.
• Surface must be absorptive to allow penetration.

For older concrete, pressure washing and cleaning with products such as Orange Peel or Berry Clean may be necessary.

New Concrete Requirements

• Allow a minimum curing period of 21 days.
• Ensure concrete is dry and free of curing residue.
• Test a small area before full application.

Application Equipment

Apply using:

• Low-pressure sprayer (10–20 PSI)
• Roller
• Brush
• Broom
• Microfiber applicator for dense surfaces

Application Method

• Apply generously and evenly.
• Avoid puddling or standing material.
• Highly porous surfaces may require additional wet-on-wet coats.
• Do not allow excess material to dry on the surface.

---

Coverage Rates

Coverage varies based on substrate porosity:

Actual coverage should always be verified with a field test area.

---

Performance Properties

Water Repellency

Creates a highly water-resistant barrier while maintaining substrate breathability.

Oil Resistance

Provides enhanced resistance to motor oil, grease, food stains, and other liquid contaminants.

UV Resistance

Excellent resistance to UV degradation and weather exposure.

Freeze-Thaw Protection

Reduces moisture absorption that contributes to freeze-thaw damage and concrete deterioration.

Appearance

• Water clear
• Non-yellowing
• Penetrating finish
• Skid resistant
• Tack free after drying

---

Packaging

Available in:

• 1-Gallon Jugs (4 per case)
• 5-Gallon Pails
• 55-Gallon Drums

---

Shelf Life & Storage

Shelf Life

• 12 months from manufacture date when stored properly.

Storage Conditions

• Store in original sealed containers.
• Protect from contamination.
• Store in a cool, dry location.
• Avoid freezing and extreme temperatures.

---

Frequently Asked Questions

What is All Shield WB used for?

All Shield WB is used to protect concrete, brick, pavers, and stone from oil stains, water intrusion, food stains, deicing salts, and environmental damage.

Does All Shield WB change the appearance of concrete?

No. It is a penetrating sealer that dries clear and does not create a visible film or glossy coating.

Can All Shield WB be used outdoors?

Yes. It is designed for both interior and exterior applications including parking structures, driveways, bridges, and marine platforms.

Does it protect against oil stains?

Yes. All Shield WB is specifically formulated to resist motor oil, grease, food stains, and many liquid contaminants.

Can it be used on natural stone?

Yes. It is suitable for natural stone, manufactured stone, brick, concrete pavers, and concrete surfaces.

How long should new concrete cure before application?

New concrete should be allowed to cure for at least 21 days before applying All Shield WB.

---

Technical Data Summary (TDS)

Product Type

• Modified fluoropolymer, silane/siloxane blend

Appearance

• Water clear

VOC

• Low VOC compliant

Flash Point

• Greater than 200°F

UV Resistance

• Excellent

Coverage

• 150–800 sq ft per gallon depending on surface porosity

Application Surfaces

• Concrete
• Brick
• Stone
• Pavers
• Masonry

Use Locations

• Interior
• Exterior

Packaging

• 1 Gallon
• 5 Gallon
• 55 Gallon

Shelf Life

• 12 Months

Safety Data Summary (SDS)

Hazard Information

All Shield WB may cause:

• Eye irritation
• Mild skin irritation
• Respiratory irritation if aerosolized
• Harmful effects if swallowed in large quantities

The product should not be aerosolized during application.

Recommended PPE

• Safety glasses or goggles
• Protective gloves
• Respiratory protection when spraying
• Protective clothing

First Aid

Eye Contact

• Flush immediately with clean water and seek medical attention if irritation persists.

Skin Contact

• Wash with soap and water.

Inhalation

• Move to fresh air.

Ingestion

• Seek medical attention if symptoms occur.

Storage

• Keep containers tightly sealed.
• Store in a dry location.
• Prevent contamination.
• Protect from freezing.

Specifications

Composition	Modified fluoropolymer, siloxane/silane blend
Appearance	Water clear
VOC	<100 g/L
UV Resistance	Excellent
Coverage (porous surfaces)	150–200 sq ft/gal
Coverage (dense/polished concrete)	800–1,200 sq ft/gal
Application Method	Low-pressure sprayer (<50 psi)
New Concrete Cure Time	Minimum 21 days before application
Shelf Life	2 years from date of manufacture

Supporting Documents

Safety Data Sheet (SDS)

Technical Data Sheet (TDS)
