5W VHF/UHF Analog Portable Radios for top-of-the-line communications - Call for bulk orders

NX-1200AV/1300AU

Analog - FM

Digital – NXDN^® Mode (Optional License required)

Digital – DMR Mode (Optional License required)

Features

Choose from direct & intuitive LCD with standard keypad or basic enclosures
Easy visible Display: 8-digit LCD models featuring high-contrast, white backlit LCD
Large 7-Color LED indicator on the top panel
Selective Power-on LED
Selective Call Alert LED
Battery Level Indication
Multi-status function indication
RF output power 5W both on VHF/UHF
Renowned KENWOOD Audio Quality: TX/RX audio profile with optimizable
digital processor
Audio Equalizer: Flat, High, Low
Auto Gain Control: On, High, Low, Off
Noise Suppressor
Microphone type settings
Multiple Scan Functions; Dual Priority, Single Priority, Single Zone, Multi,
Normal Scan
VOX & PTT –triggered Semi- VOX, Voice-operated TX
Emergency Function: Customizable Emergency Profile
Lone Worker
Max / Min Volume setting & Volume control
Voice Announcement
Remote Stun / Kill / Check
Front Panel Programming Mode (for Keypad model)
Electronic Serial Number (ESN)
MIL-STD-810 C/D/E/F/G
IP54 and IP55
Multi-protocol digital radio: Designed to operate under NXDN or DMR digital and FM
analog protocols (Optional License required)

SPECIFICATIONS

General		NX-1200AV	NX-1300AU
Pre-set Frequencies	Type 1	136-174 MHz	450-520 MHz
Pre-set Frequencies	Type 2		400-470 MHz
Max. Channels per Radio		260 (64 for basic model)
Number of Zones		128 (4 for basic model)
Max. Channels per Zone		250 (16 for basic model)
Channel Spacing	Analog	301 / 251 / 15 / 12.5 kHz
Channel Spacing	Digital	12.5 / 6.25 kHz
Power Supply		7.5 VDC ±20 %
Battery Life		DMR	Analog/NXDN
KNB-45L (2000mAh)		Approx. 14.5 hours (15 hours for Basic model)	Approx. 11 hours (11.5 hours for Basic model)
KNB-69L (2550mAh)		Approx. 19 hours (19.5 hours for Basic model)	Approx. 14 hours (14.5 hours for Basic model)
Operating Temperature (Radio only) *2		-22°F to +140°F (-30°C to +60°C)
Frequency Stability (-30 to +60°C; +25°C Ref.)		±0.5 ppm
Antenna Impedance		50 Ω
Dimensions		(W x H x D) Projections Not Included
Radio with KNB-45L
